PKS0201A10-USRD

2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub

(Previously PKS0201A10)

Regular price
$129.99
Regular price
Sale price
$129.99
Shipping calculated at checkout.

Note: The current available batches do not include an EDID emulator. If you need assistance, please contact customer service.

  • The KVM switch comes with complete PC cables. 2* DP/USB to the computers are included.
  • High resolution up to 3840*2160@60Hz 4:4:4, HDMI 2.0 and HDCP 2.2 compliant.
  • Using only 1 set of keyboard, mouse, and monitor to control 2 computers.
  • Switching via front panel buttons, keyboard hotkeys, IR remote control, and mouse gestures.
  • Support keyboard and mouse pass-through mode to improve KM compatibility.
  • Support auto switching to monitor computers in a specified time interval
2-PC KVM Switch Models Comparison:
Model Edition Resolution USB Hub Audio Pass-Through
HKS201-P23 Prime 4K@60Hz USB 3.0 Audio I/O Yes
HKS201-E23 Elite 4K@60Hz USB 2.0 Audio Out Yes
DKS201-E23 Elite 4K@60Hz USB 2.0 Audio Out Yes


    Plug Type
    Color – Red
    Check if the product's ports match your device.
    • Number of connectable computers: 2
    • Number of connectable monitors: 1
    • Type of input port(s): 2*(DP+USB-B)
    • Type of output port(s): DP
    • Max Resolution: 4K@60Hz
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub

      Quick view
      2 Port DisplayPort 1.2 KVM Switch 4K60Hz with USB Hub
      Regular price
      $129.99
      Regular price
      Sale price
      $129.99

      Tech Specs

      Description

      This 2-Port DP KVM Switch provides you with great flexibility in integrating cross-platform computer equipment easily. It makes you available to share one set of keyboard, mouse and monitor with two PCs. The 2-Port DP KVM Switch supports resolution up to 4K@60Hz. Support USB 2.0 hub and USB 2.0 keyboard /mouse. By using USB 2.0 hub ports on the KVM, you even can attach USB drive, printer, barcode scanner or other USB devices to the KVM. Switching can be controlled through variable methods, such as the front panel buttons, IR signals, keyboard hot keys, etc. Support keyboard and mouse pass through mode to improve KM compatibility.

      Packing List
      • 1 * 2x1 DP KVM Switch
      • 2 * DP Cables
      • 2 * USB Cables
      • 1 * DC 5V Power Adapter
      • 1 * IR Remote Control
      • 1 * User Manual
      Key Features
      • Using only 1 set of keyboard, mouse and monitor to control 2 PCs.
      • Support resolution up to 3840*2160@60Hz.
      • Support auto switching to monitor computers in a specified time interval.
      • Available to use keyboard and mouse without any delay after switching inputs.
      • Support hot plug, connect or disconnect devices to the KVM switch at any time without turning off devices.
      • Support front panel buttons, IR signals, keyboard hot keys and mouse gesture to control KVM to switch inputs.
      • With extra standard USB 2.0 hub port, it is possible to connect barcode scanner, USB hard drive or other USB devices to KVM just as you have plug these devices directly to computer.
      • Support mouse and keyboard pass through mode to improve KM compatibility.
      Support Systems

      Support Unix/Windows/Debian/Ubuntu/Fedora/Mac OS X/Raspbian/Ubuntu for Raspberry Pi and other Linux based systems.

      Safety Measures
      • Please use 5V power supply for product installation. Using the wrong power supply can cause damage to the product and even to your equipment.
      • Cables (including power and charging cables) should be placed and routed to avoid creating electric, tripping or safety hazards.
      • If product has an exposed circuit board, do not touch the product under power.
