HDMI Extender KVM Over TCP/IP Ethernet Via Single Cat5e/6 Cable 1080P with IR - Up to 120m

Overview

The 120M HDMI KVM Many to Many Over IP Extender with IR (HKE12MMA10), Support USB keyboard and mouse data, IR signal transmitted over a LAN (Local Area Network). Support input resolution up to 1080P Full HD. According to 1000M IGMP network switch, source content can be transmitted from several transmitters (Up to 16 transmitters) to several receivers (Up to 253 receivers) over LAN, and the transmitter can be controlled by either of the receivers in the same local area network by IR or USB keyboard and mouse. This product can be used on remote DVR for Security System, servers in data centre and monitor room.

Features

• Support resolution up to 1080p Full HD
• Support TMDS equalization and enhancement
• By transmitting keyboard and mouse Datas via LAN, it is easy to control PC or other media players remotely
• Routes up to 16 transmitters to 253 receivers by 1000M IGMP network switch
• Support infrared remote control signal pass through
• Support Fiber-Optic converter to extend transmission distance up to 20KM
• Complies with TCP / IP protocol (image will be compressed)

Diagram

Simple Setup: a transmitter and a receiver

This device uses over CAT5/6 cables to extend the HDMI signal up to 393ft at 1080p@60Hz. It breaks the limitation of HDMI cable lengths and has more flexibility and convenience for installation. The extender system consists of a transmitter(TX) and a receiver(RX). Connect your HDMI source such as PC, game console, Blu-ray player and media player to the Transmitter with an HDMI cable.

Up to 16 transmitters to 253 receivers

By using 1000M IGMP network switch, source content can be transmitted from several transmitters (Up to 16 transmitters) to several receivers (Up to 253 receivers) over LAN, and the transmitter can be controlled by either of the receivers in the same local area network by IR or USB keyboard and mouse.

With EDID virtual display

This KVM Switch has EDID emulators in each input port, which helps to keep PCs always having correct display information, prevent display settings from changing while switching input ports.

• 1 * HDMI KVM Extender Sender
• 1 * HDMI KVM Extender Receiver
• 2 * DC 5V 1A Power Adapter
• 1 * IR Sender extension cable
• 1 * IR Receiver extension cable
• 1 * User manual

Q1: Why the direct one to one connection cannot be used？
A: You must use a super Cat5 / 6e network cable (wire sequence T-568B), please check if the addresses of the DIP switches of the transmitter and receiver match.

Q2: Why does "Check input signal" appear on the screen?
A: The input signal is inaccessible, please check if the source of the HDMI input signal is connected normally. It is recommended to replace the shorter HDMI cable. Input signal recommended within 5 meters.

Q3: What does "Searching TX" on the screen mean?
A: The network cable is partially disconnected, please check if the network cable is normal. It is recommended to use Super Category 5 and Category 6 network cables.
